{"id":6890245390423,"title":"Vortiflo Complete Vortex Flow Control Chamber 300 and 450mm","handle":"vortiflo-complete-vortex-flow-control-chamber-300-and-450mm","description":"\u003cp\u003eThe Vortiflo range is a series of Vortex Flow Control Chambers accommodating a range of flow rates available in 300mm and 450mm diameter, pre-assembled flow control chamber, delivered ready to install\u003c\/p\u003e\n\u003cp\u003eThe VFCC300 and VFCC450 model are designed for flow rates up to 2.1 L\/sec dependent on design head\u003c\/p\u003e\n\u003cp\u003eThe larger diameter models in the Vortiflo range accommodate a larger flow rate and taller design head tolerance if required.\u003c\/p\u003e\n\u003cp\u003eThis model has a rotational moulded chamber base with 110mm or 160mm main channel socket connections including two further 110mm (or 160mm for 450mm chamber) side inlets at 90°, 270° from the outlet at 0°. Side inlets are supplied as blanked ends that can be used as require\u003c\/p\u003e\n\u003cp\u003e\u003cstrong\u003e\u003cspan style=\"text-decoration: underline;\"\u003eSpecification\u003c\/span\u003e\u003c\/strong\u003e\u003c\/p\u003e\n\u003cp\u003eThe Vortiflo VFCC300 and VFCC450 models both features our FlowBrake mini - vortex flow control is specifically designed for small housing plot attenuation, where the installation of an orifice plates, would not be suitable, particularly within adoptable installations and many localised building requirements, due to the Orifice size, which would be in most cases be below 20mm.\u003c\/p\u003e\nDesigned to facilitate such discharge flows from 0.2 to 1.5 litres per second with a design\n\u003cp\u003ehead of between 0.2 and 1.5 metres the Flowbrake Mini offers an extremely effective flow control device.\u003c\/p\u003e\n\u003cp\u003e\u003cstrong\u003e*These are not supplied with a lid*\u003c\/strong\u003e\u003c\/p\u003e\n\u003cp\u003e\u003cstrong\u003e\u003c\/strong\u003e\u003cstrong\u003e\u003cspan style=\"text-decoration: underline;\" data-mce-style=\"text-decoration: underline;\"\u003eOptional Accessories\u003c\/span\u003e\u003cbr\u003e\u003c\/strong\u003e\u003c\/p\u003e\n\u003cp\u003e\u003cspan style=\"text-decoration: underline;\" data-mce-style=\"text-decoration: underline;\"\u003e\u003c\/span\u003e\u003ca href=\"https:\/\/www.freeflush.co.uk\/products\/accesso-chamber-access-covers?_pos=6\u0026amp;_sid=5226bbc75\u0026amp;_ss=r\"\u003e300mm Cover\u003c\/a\u003e - 1.5T loading, 300mm square lid\u003c\/p\u003e\n\u003cp\u003e\u003ca href=\"https:\/\/www.freeflush.co.uk\/products\/accesso-chamber-access-covers?variant=40064747241559\"\u003e450mm Cover\u003c\/a\u003e - 1.5T loading, 450mm square lid\u003c\/p\u003e\n\u003cp\u003e\u003cspan style=\"text-decoration: underline;\" data-mce-style=\"text-decoration: underline;\"\u003e\u003cstrong\u003eOptional Accessories\u003c\/strong\u003e\u003c\/span\u003e \u003cbr\u003e\u003c\/p\u003e\n\u003cul data-mce-fragment=\"1\"\u003e\n\u003cli data-mce-fragment=\"1\"\u003e\u003ca data-mce-fragment=\"1\" href=\"https:\/\/www.freeflush.co.uk\/collections\/stormwater-attenuation-accessories\/products\/oriflo-flow-control-chamber-300mm-p-series\" data-mce-href=\"https:\/\/www.freeflush.co.uk\/collections\/stormwater-attenuation-accessories\/products\/oriflo-flow-control-chamber-300mm-p-series\"\u003eSilt Guard upstream protection\u003c\/a\u003e\u003c\/li\u003e\n\u003cli data-mce-fragment=\"1\"\u003e\n\u003ca href=\"https:\/\/www.freeflush.co.uk\/collections\/stormwater-attenuation-accessories\/products\/oriflo-flow-control-chamber-300mm-p-series\" data-mce-href=\"https:\/\/www.freeflush.co.uk\/collections\/stormwater-attenuation-accessories\/products\/oriflo-flow-control-chamber-300mm-p-series\"\u003e\u003cspan style=\"text-decoration: underline;\" data-mce-style=\"text-decoration: underline;\"\u003eSuDs attenuation sizing design\u003c\/span\u003e\u003c\/a\u003e\u003cbr\u003e\n\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003cp\u003e\u003cstrong\u003e\u003cspan style=\"text-decoration: underline;\" data-mce-style=\"text-decoration: underline;\"\u003eDimensions\u003c\/span\u003e\u003c\/strong\u003e\u003c\/p\u003e\n\u003cstyle type=\"text\/css\"\u003e\u003c!--\ntd {border: 1px solid #cccccc;}br {mso-data-placement:same-cell;}\n--\u003e\u003c\/style\u003e\n\u003cstyle type=\"text\/css\"\u003e\u003c!--\ntd {border: 1px solid #cccccc;}br {mso-data-placement:same-cell;}\n--\u003e\u003c\/style\u003e\n\u003ctable xmlns=\"http:\/\/www.w3.org\/1999\/xhtml\" cellspacing=\"0\" cellpadding=\"0\" dir=\"ltr\" border=\"1\"\u003e\n\u003ccolgroup\u003e \u003ccol width=\"190\"\u003e \u003ccol width=\"144\"\u003e \u003ccol width=\"162\"\u003e \u003ccol width=\"100\"\u003e \u003ccol width=\"89\"\u003e \u003ccol width=\"74\"\u003e \u003ccol width=\"100\"\u003e \u003ccol width=\"100\"\u003e \u003c\/colgroup\u003e\n\u003ctbody\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"Product Code\"}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eProduct Code\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"Main pipework options Ø\\n(mm)\"}' data-mce-style=\"text-align: center;\"\u003e\n\u003cstrong\u003eMain pipework options Ø\u003c\/strong\u003e\u003cbr\u003e\u003cstrong\u003e(mm)\u003c\/strong\u003e\n\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"Optional Side Inlets \\n(mm)\\n\"}' data-mce-style=\"text-align: center;\"\u003e\n\u003cstrong\u003eOptional Side Inlets \u003c\/strong\u003e\u003cbr\u003e\u003cstrong\u003e(mm)\u003c\/strong\u003e\u003cbr\u003e\n\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"Overall\\r\\nDepth\\r\\nA (mm)\"}' data-sheets-textstyleruns='{\"1\":0,\"2\":{\"3\":\"Arial\"}}{\"1\":16,\"2\":{\"3\":\"Arial\",\"5\":1}}{\"1\":17,\"2\":{\"3\":\"Arial\"}}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eOverall \u003cbr\u003eDepth \u003cbr\u003eA (mm)\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"Inlet\\r\\nInvert\\r\\nB (mm)\"}' data-sheets-textstyleruns='{\"1\":0,\"2\":{\"3\":\"Arial\"}}{\"1\":15,\"2\":{\"3\":\"Arial\",\"5\":1}}{\"1\":16,\"2\":{\"3\":\"Arial\"}}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eInlet \u003cbr\u003eInvert \u003cbr\u003eB (mm)\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"Outlet\\r\\nInvert\\r\\nC (mm)\"}' data-sheets-textstyleruns='{\"1\":0,\"2\":{\"3\":\"Arial\"}}{\"1\":16,\"2\":{\"3\":\"Arial\",\"5\":1}}{\"1\":18,\"2\":{\"3\":\"Arial\"}}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eOutlet \u003cbr\u003eInvert \u003cbr\u003eC (mm)\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"Chamber\\nØ\\n(mm)\"}' data-sheets-textstyleruns='{\"1\":0}{\"1\":8,\"2\":{\"5\":1}}{\"1\":9}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eChamber\u003cbr\u003eØ\u003cbr\u003e(mm)\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"Approx.\\r\\nWeight\\n(kg)\"}' data-mce-style=\"text-align: center;\"\u003e\n\u003cstrong\u003eApprox. \u003c\/strong\u003e\u003cbr\u003e\u003cstrong\u003eWeight\u003c\/strong\u003e\u003cbr\u003e\u003cstrong\u003e(kg)\u003c\/strong\u003e\n\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"VFCC300\/2\"}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eVFCC300\/2\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"110 -160\"}' data-mce-style=\"text-align: center;\"\u003e110 -160\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":110}' data-mce-style=\"text-align: center;\"\u003e110\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":2030}' data-mce-style=\"text-align: center;\"\u003e2030\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":1700}' data-mce-style=\"text-align: center;\"\u003e1700\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":1755}' data-mce-style=\"text-align: center;\"\u003e1755\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":300}' data-mce-style=\"text-align: center;\"\u003e300\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":22.5}' data-mce-style=\"text-align: center;\"\u003e22.5\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"VFCC450\/2\"}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eVFCC450\/2\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"110 -160\"}' data-mce-style=\"text-align: center;\"\u003e110 -160\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"110 -160\"}' data-mce-style=\"text-align: center;\"\u003e110 -160\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":1950}' data-mce-style=\"text-align: center;\"\u003e1950\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":1630}' data-mce-style=\"text-align: center;\"\u003e1630\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":1650}' data-mce-style=\"text-align: center;\"\u003e1650\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":450}' data-mce-style=\"text-align: center;\"\u003e450\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":24.5}' data-mce-style=\"text-align: center;\"\u003e24.5\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"VFCC450\/2.4\"}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eVFCC450\/2.4\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"110 -160\"}' data-mce-style=\"text-align: center;\"\u003e110 -160\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"110 -160\"}' data-mce-style=\"text-align: center;\"\u003e110 -160\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":2410}' data-mce-style=\"text-align: center;\"\u003e2410\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":2090}' data-mce-style=\"text-align: center;\"\u003e2090\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":2110}' data-mce-style=\"text-align: center;\"\u003e2110\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":450}' data-mce-style=\"text-align: center;\"\u003e450\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":29}' data-mce-style=\"text-align: center;\"\u003e29\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"VFCC450\/3\"}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eVFCC450\/3\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"110 -160\"}' data-mce-style=\"text-align: center;\"\u003e110 -160\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"110 -160\"}' data-mce-style=\"text-align: center;\"\u003e110 -160\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":3025}' data-mce-style=\"text-align: center;\"\u003e3025\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":2705}' data-mce-style=\"text-align: center;\"\u003e2705\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":2725}' data-mce-style=\"text-align: center;\"\u003e2725\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":450}' data-mce-style=\"text-align: center;\"\u003e450\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":34.5}' data-mce-style=\"text-align: center;\"\u003e34.5\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"VFCC450225\/2 (Twinwall)\"}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eVFCC450225\/2 (Twinwall)\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"150−225\"}' data-mce-style=\"text-align: center;\"\u003e150−225\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":150}' data-mce-style=\"text-align: center;\"\u003e150\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":2000}' data-mce-style=\"text-align: center;\"\u003e2000\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":1700}' data-mce-style=\"text-align: center;\"\u003e1700\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":1755}' data-mce-style=\"text-align: center;\"\u003e1755\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":450}' data-mce-style=\"text-align: center;\"\u003e450\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":26}' data-mce-style=\"text-align: center;\"\u003e26\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"VFCC450225\/2.4 (Twinwall)\"}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eVFCC450225\/2.4 (Twinwall)\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"150−225\"}' data-mce-style=\"text-align: center;\"\u003e150−225\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":150}' data-mce-style=\"text-align: center;\"\u003e150\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":2370}' data-mce-style=\"text-align: center;\"\u003e2370\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":2070}' data-mce-style=\"text-align: center;\"\u003e2070\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":1755}' data-mce-style=\"text-align: center;\"\u003e1755\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":450}' data-mce-style=\"text-align: center;\"\u003e450\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":31}' data-mce-style=\"text-align: center;\"\u003e31\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"VFCC450225\/3 (Twinwall)\"}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eVFCC450225\/3 (Twinwall)\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"150−225\"}' data-mce-style=\"text-align: center;\"\u003e150−225\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":150}' data-mce-style=\"text-align: center;\"\u003e150\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":3000}' data-mce-style=\"text-align: center;\"\u003e3000\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":2700}' data-mce-style=\"text-align: center;\"\u003e2700\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":1755}' data-mce-style=\"text-align: center;\"\u003e1755\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":450}' data-mce-style=\"text-align: center;\"\u003e450\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":37.5}' data-mce-style=\"text-align: center;\"\u003e37.5\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003cspan style=\"text-decoration: underline;\" data-mce-style=\"text-decoration: underline;\"\u003e\u003cstrong\u003e\u003c\/strong\u003e\u003c\/span\u003e \u003cbr\u003e\u003cspan style=\"text-decoration: underline;\" data-mce-style=\"text-decoration: underline;\"\u003e\u003cstrong\u003eGuidance Documents \u003cbr\u003e\u003c\/strong\u003e\u003c\/span\u003e\n\u003cp\u003eThe FlowBrake mini meets the criteria of the following SuDS design documents\u003c\/p\u003e\n\u003cp\u003eBS 8582 9.6\u003c\/p\u003e\n\u003cp\u003eCIRIA 753 10.2, 20.5  \u003cbr\u003e\u003c\/p\u003e\n\u003cp\u003eThe FlowBrake mini has a minimum opening of 20mm which is considered suitable where upstream blockage prevention is in place.\u003c\/p\u003e\n\u003cp\u003e\u003c!-- split --\u003e DAT file for 20mm inlet: 20mm outlet\u003cbr data-mce-fragment=\"1\"\u003e\u003cbr data-mce-fragment=\"1\"\u003eDAT file for 25mm inlet: 25mm outlet\u003cbr data-mce-fragment=\"1\"\u003e\u003cbr data-mce-fragment=\"1\"\u003eDAT file for 36mm inlet: 36mm outlet\u003cbr\u003e\u003c\/p\u003e\n\u003cp\u003e \u003c\/p\u003e\n\u003cp\u003e\u003ca href=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0829\/4323\/files\/VFCC300_VFCC450_DATA_SHEET.pdf?v=1697456667\"\u003e\u003cstrong\u003eVFCC300\u0026amp;450 Data Sheet\u003c\/strong\u003e\u003c\/a\u003e\u003c\/p\u003e","published_at":"2023-10-16T14:49:36+01:00","created_at":"2023-07-03T13:02:28+01:00","vendor":"TurtleEnviro","type":"stormwater management","tags":[],"price":98900,"price_min":98900,"price_max":143900,"available":true,"price_varies":true,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":40208157507671,"title":"300 \/ 1700 \/ 2030 \/ 110 - 160","option1":"300","option2":"1700 \/ 2030","option3":"110 - 160","sku":"VFCC300\/2","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Vortiflo Complete Vortex Flow Control Chamber 300 and 450mm - 300 \/ 1700 \/ 2030 \/ 110 - 160","public_title":"300 \/ 1700 \/ 2030 \/ 110 - 160","options":["300","1700 \/ 2030","110 - 160"],"price":98900,"weight":46000,"compare_at_price":null,"inventory_quantity":0,"inventory_management":null,"inventory_policy":"deny","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[]},{"id":40281771409495,"title":"450 \/ 1630 \/ 1950 \/ 110 - 160","option1":"450","option2":"1630 \/ 1950","option3":"110 - 160","sku":"VFCC450\/2","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Vortiflo Complete Vortex Flow Control Chamber 300 and 450mm - 450 \/ 1630 \/ 1950 \/ 110 - 160","public_title":"450 \/ 1630 \/ 1950 \/ 110 - 160","options":["450","1630 \/ 1950","110 - 160"],"price":106900,"weight":46000,"compare_at_price":null,"inventory_quantity":0,"inventory_management":null,"inventory_policy":"deny","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":40281771442263,"title":"450 \/ 2090 \/ 2410 \/ 110 - 160","option1":"450","option2":"2090 \/ 2410","option3":"110 - 160","sku":"VFCC450\/2.4","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Vortiflo Complete Vortex Flow Control Chamber 300 and 450mm - 450 \/ 2090 \/ 2410 \/ 110 - 160","public_title":"450 \/ 2090 \/ 2410 \/ 110 - 160","options":["450","2090 \/ 2410","110 - 160"],"price":122900,"weight":46000,"compare_at_price":null,"inventory_quantity":0,"inventory_management":null,"inventory_policy":"deny","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":40281771475031,"title":"450 \/ 2705 \/ 3025 \/ 110 - 160","option1":"450","option2":"2705 \/ 3025","option3":"110 - 160","sku":"VFCC450\/3","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Vortiflo Complete Vortex Flow Control Chamber 300 and 450mm - 450 \/ 2705 \/ 3025 \/ 110 - 160","public_title":"450 \/ 2705 \/ 3025 \/ 110 - 160","options":["450","2705 \/ 3025","110 - 160"],"price":139900,"weight":46000,"compare_at_price":null,"inventory_quantity":0,"inventory_management":null,"inventory_policy":"deny","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":40281783992407,"title":"450 \/ 1700 \/ 2000 \/ 150 - 225","option1":"450","option2":"1700 \/ 2000","option3":"150 - 225","sku":"VFCC450225\/2","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Vortiflo Complete Vortex Flow Control Chamber 300 and 450mm - 450 \/ 1700 \/ 2000 \/ 150 - 225","public_title":"450 \/ 1700 \/ 2000 \/ 150 - 225","options":["450","1700 \/ 2000","150 - 225"],"price":110900,"weight":46000,"compare_at_price":null,"inventory_quantity":0,"inventory_management":null,"inventory_policy":"deny","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":40281784025175,"title":"450 \/ 2070 \/ 2370 \/ 150 - 225","option1":"450","option2":"2070 \/ 2370","option3":"150 - 225","sku":"VFCC450225\/2.4","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Vortiflo Complete Vortex Flow Control Chamber 300 and 450mm - 450 \/ 2070 \/ 2370 \/ 150 - 225","public_title":"450 \/ 2070 \/ 2370 \/ 150 - 225","options":["450","2070 \/ 2370","150 - 225"],"price":127900,"weight":46000,"compare_at_price":null,"inventory_quantity":0,"inventory_management":null,"inventory_policy":"deny","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":40281784057943,"title":"450 \/ 2700 \/ 3000 \/ 150 - 225","option1":"450","option2":"2700 \/ 3000","option3":"150 - 225","sku":"VFCC450225\/3","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Vortiflo Complete Vortex Flow Control Chamber 300 and 450mm - 450 \/ 2700 \/ 3000 \/ 150 - 225","public_title":"450 \/ 2700 \/ 3000 \/ 150 - 225","options":["450","2700 \/ 3000","150 - 225"],"price":143900,"weight":46000,"compare_at_price":null,"inventory_quantity":0,"inventory_management":null,"inventory_policy":"deny","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]}],"images":["\/\/www.freeflush.co.uk\/cdn\/shop\/files\/flowbrakechamber_e373d67c-932e-4631-8770-8da7199ce682.jpg?v=1688385760","\/\/www.freeflush.co.uk\/cdn\/shop\/files\/VFCC300Dims.png?v=1697456601","\/\/www.freeflush.co.uk\/cdn\/shop\/files\/flowbrakepelican_17cc0db2-4657-4361-a4e4-b13cb6d730ec.jpg?v=1697456601","\/\/www.freeflush.co.uk\/cdn\/shop\/files\/VFCC300450Internal.jpg?v=1697456601","\/\/www.freeflush.co.uk\/cdn\/shop\/files\/VFCC300450Curves.jpg?v=1697456601"],"featured_image":"\/\/www.freeflush.co.uk\/cdn\/shop\/files\/flowbrakechamber_e373d67c-932e-4631-8770-8da7199ce682.jpg?v=1688385760","options":["Chamber Diameter (mm)","Inlet\/Total Depth (mm)","Main Pipework Connection (mm)"],"media":[{"alt":null,"id":22876640411735,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1280,"width":1280,"src":"\/\/www.freeflush.co.uk\/cdn\/shop\/files\/flowbrakechamber_e373d67c-932e-4631-8770-8da7199ce682.jpg?v=1688385760"},"aspect_ratio":1.0,"height":1280,"media_type":"image","src":"\/\/www.freeflush.co.uk\/cdn\/shop\/files\/flowbrakechamber_e373d67c-932e-4631-8770-8da7199ce682.jpg?v=1688385760","width":1280},{"alt":null,"id":23222071787607,"position":2,"preview_image":{"aspect_ratio":0.915,"height":656,"width":600,"src":"\/\/www.freeflush.co.uk\/cdn\/shop\/files\/VFCC300Dims.png?v=1697456601"},"aspect_ratio":0.915,"height":656,"media_type":"image","src":"\/\/www.freeflush.co.uk\/cdn\/shop\/files\/VFCC300Dims.png?v=1697456601","width":600},{"alt":null,"id":22876640673879,"position":3,"preview_image":{"aspect_ratio":1.601,"height":1011,"width":1619,"src":"\/\/www.freeflush.co.uk\/cdn\/shop\/files\/flowbrakepelican_17cc0db2-4657-4361-a4e4-b13cb6d730ec.jpg?v=1697456601"},"aspect_ratio":1.601,"height":1011,"media_type":"image","src":"\/\/www.freeflush.co.uk\/cdn\/shop\/files\/flowbrakepelican_17cc0db2-4657-4361-a4e4-b13cb6d730ec.jpg?v=1697456601","width":1619},{"alt":null,"id":23222079979607,"position":4,"preview_image":{"aspect_ratio":0.943,"height":848,"width":800,"src":"\/\/www.freeflush.co.uk\/cdn\/shop\/files\/VFCC300450Internal.jpg?v=1697456601"},"aspect_ratio":0.943,"height":848,"media_type":"image","src":"\/\/www.freeflush.co.uk\/cdn\/shop\/files\/VFCC300450Internal.jpg?v=1697456601","width":800},{"alt":null,"id":23222050422871,"position":5,"preview_image":{"aspect_ratio":1.32,"height":634,"width":837,"src":"\/\/www.freeflush.co.uk\/cdn\/shop\/files\/VFCC300450Curves.jpg?v=1697456601"},"aspect_ratio":1.32,"height":634,"media_type":"image","src":"\/\/www.freeflush.co.uk\/cdn\/shop\/files\/VFCC300450Curves.jpg?v=1697456601","width":837}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003cp\u003eThe Vortiflo range is a series of Vortex Flow Control Chambers accommodating a range of flow rates available in 300mm and 450mm diameter, pre-assembled flow control chamber, delivered ready to install\u003c\/p\u003e\n\u003cp\u003eThe VFCC300 and VFCC450 model are designed for flow rates up to 2.1 L\/sec dependent on design head\u003c\/p\u003e\n\u003cp\u003eThe larger diameter models in the Vortiflo range accommodate a larger flow rate and taller design head tolerance if required.\u003c\/p\u003e\n\u003cp\u003eThis model has a rotational moulded chamber base with 110mm or 160mm main channel socket connections including two further 110mm (or 160mm for 450mm chamber) side inlets at 90°, 270° from the outlet at 0°. Side inlets are supplied as blanked ends that can be used as require\u003c\/p\u003e\n\u003cp\u003e\u003cstrong\u003e\u003cspan style=\"text-decoration: underline;\"\u003eSpecification\u003c\/span\u003e\u003c\/strong\u003e\u003c\/p\u003e\n\u003cp\u003eThe Vortiflo VFCC300 and VFCC450 models both features our FlowBrake mini - vortex flow control is specifically designed for small housing plot attenuation, where the installation of an orifice plates, would not be suitable, particularly within adoptable installations and many localised building requirements, due to the Orifice size, which would be in most cases be below 20mm.\u003c\/p\u003e\nDesigned to facilitate such discharge flows from 0.2 to 1.5 litres per second with a design\n\u003cp\u003ehead of between 0.2 and 1.5 metres the Flowbrake Mini offers an extremely effective flow control device.\u003c\/p\u003e\n\u003cp\u003e\u003cstrong\u003e*These are not supplied with a lid*\u003c\/strong\u003e\u003c\/p\u003e\n\u003cp\u003e\u003cstrong\u003e\u003c\/strong\u003e\u003cstrong\u003e\u003cspan style=\"text-decoration: underline;\" data-mce-style=\"text-decoration: underline;\"\u003eOptional Accessories\u003c\/span\u003e\u003cbr\u003e\u003c\/strong\u003e\u003c\/p\u003e\n\u003cp\u003e\u003cspan style=\"text-decoration: underline;\" data-mce-style=\"text-decoration: underline;\"\u003e\u003c\/span\u003e\u003ca href=\"https:\/\/www.freeflush.co.uk\/products\/accesso-chamber-access-covers?_pos=6\u0026amp;_sid=5226bbc75\u0026amp;_ss=r\"\u003e300mm Cover\u003c\/a\u003e - 1.5T loading, 300mm square lid\u003c\/p\u003e\n\u003cp\u003e\u003ca href=\"https:\/\/www.freeflush.co.uk\/products\/accesso-chamber-access-covers?variant=40064747241559\"\u003e450mm Cover\u003c\/a\u003e - 1.5T loading, 450mm square lid\u003c\/p\u003e\n\u003cp\u003e\u003cspan style=\"text-decoration: underline;\" data-mce-style=\"text-decoration: underline;\"\u003e\u003cstrong\u003eOptional Accessories\u003c\/strong\u003e\u003c\/span\u003e \u003cbr\u003e\u003c\/p\u003e\n\u003cul data-mce-fragment=\"1\"\u003e\n\u003cli data-mce-fragment=\"1\"\u003e\u003ca data-mce-fragment=\"1\" href=\"https:\/\/www.freeflush.co.uk\/collections\/stormwater-attenuation-accessories\/products\/oriflo-flow-control-chamber-300mm-p-series\" data-mce-href=\"https:\/\/www.freeflush.co.uk\/collections\/stormwater-attenuation-accessories\/products\/oriflo-flow-control-chamber-300mm-p-series\"\u003eSilt Guard upstream protection\u003c\/a\u003e\u003c\/li\u003e\n\u003cli data-mce-fragment=\"1\"\u003e\n\u003ca href=\"https:\/\/www.freeflush.co.uk\/collections\/stormwater-attenuation-accessories\/products\/oriflo-flow-control-chamber-300mm-p-series\" data-mce-href=\"https:\/\/www.freeflush.co.uk\/collections\/stormwater-attenuation-accessories\/products\/oriflo-flow-control-chamber-300mm-p-series\"\u003e\u003cspan style=\"text-decoration: underline;\" data-mce-style=\"text-decoration: underline;\"\u003eSuDs attenuation sizing design\u003c\/span\u003e\u003c\/a\u003e\u003cbr\u003e\n\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003cp\u003e\u003cstrong\u003e\u003cspan style=\"text-decoration: underline;\" data-mce-style=\"text-decoration: underline;\"\u003eDimensions\u003c\/span\u003e\u003c\/strong\u003e\u003c\/p\u003e\n\u003cstyle type=\"text\/css\"\u003e\u003c!--\ntd {border: 1px solid #cccccc;}br {mso-data-placement:same-cell;}\n--\u003e\u003c\/style\u003e\n\u003cstyle type=\"text\/css\"\u003e\u003c!--\ntd {border: 1px solid #cccccc;}br {mso-data-placement:same-cell;}\n--\u003e\u003c\/style\u003e\n\u003ctable xmlns=\"http:\/\/www.w3.org\/1999\/xhtml\" cellspacing=\"0\" cellpadding=\"0\" dir=\"ltr\" border=\"1\"\u003e\n\u003ccolgroup\u003e \u003ccol width=\"190\"\u003e \u003ccol width=\"144\"\u003e \u003ccol width=\"162\"\u003e \u003ccol width=\"100\"\u003e \u003ccol width=\"89\"\u003e \u003ccol width=\"74\"\u003e \u003ccol width=\"100\"\u003e \u003ccol width=\"100\"\u003e \u003c\/colgroup\u003e\n\u003ctbody\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"Product Code\"}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eProduct Code\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"Main pipework options Ø\\n(mm)\"}' data-mce-style=\"text-align: center;\"\u003e\n\u003cstrong\u003eMain pipework options Ø\u003c\/strong\u003e\u003cbr\u003e\u003cstrong\u003e(mm)\u003c\/strong\u003e\n\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"Optional Side Inlets \\n(mm)\\n\"}' data-mce-style=\"text-align: center;\"\u003e\n\u003cstrong\u003eOptional Side Inlets \u003c\/strong\u003e\u003cbr\u003e\u003cstrong\u003e(mm)\u003c\/strong\u003e\u003cbr\u003e\n\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"Overall\\r\\nDepth\\r\\nA (mm)\"}' data-sheets-textstyleruns='{\"1\":0,\"2\":{\"3\":\"Arial\"}}{\"1\":16,\"2\":{\"3\":\"Arial\",\"5\":1}}{\"1\":17,\"2\":{\"3\":\"Arial\"}}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eOverall \u003cbr\u003eDepth \u003cbr\u003eA (mm)\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"Inlet\\r\\nInvert\\r\\nB (mm)\"}' data-sheets-textstyleruns='{\"1\":0,\"2\":{\"3\":\"Arial\"}}{\"1\":15,\"2\":{\"3\":\"Arial\",\"5\":1}}{\"1\":16,\"2\":{\"3\":\"Arial\"}}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eInlet \u003cbr\u003eInvert \u003cbr\u003eB (mm)\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"Outlet\\r\\nInvert\\r\\nC (mm)\"}' data-sheets-textstyleruns='{\"1\":0,\"2\":{\"3\":\"Arial\"}}{\"1\":16,\"2\":{\"3\":\"Arial\",\"5\":1}}{\"1\":18,\"2\":{\"3\":\"Arial\"}}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eOutlet \u003cbr\u003eInvert \u003cbr\u003eC (mm)\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"Chamber\\nØ\\n(mm)\"}' data-sheets-textstyleruns='{\"1\":0}{\"1\":8,\"2\":{\"5\":1}}{\"1\":9}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eChamber\u003cbr\u003eØ\u003cbr\u003e(mm)\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"Approx.\\r\\nWeight\\n(kg)\"}' data-mce-style=\"text-align: center;\"\u003e\n\u003cstrong\u003eApprox. \u003c\/strong\u003e\u003cbr\u003e\u003cstrong\u003eWeight\u003c\/strong\u003e\u003cbr\u003e\u003cstrong\u003e(kg)\u003c\/strong\u003e\n\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"VFCC300\/2\"}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eVFCC300\/2\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"110 -160\"}' data-mce-style=\"text-align: center;\"\u003e110 -160\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":110}' data-mce-style=\"text-align: center;\"\u003e110\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":2030}' data-mce-style=\"text-align: center;\"\u003e2030\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":1700}' data-mce-style=\"text-align: center;\"\u003e1700\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":1755}' data-mce-style=\"text-align: center;\"\u003e1755\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":300}' data-mce-style=\"text-align: center;\"\u003e300\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":22.5}' data-mce-style=\"text-align: center;\"\u003e22.5\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"VFCC450\/2\"}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eVFCC450\/2\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"110 -160\"}' data-mce-style=\"text-align: center;\"\u003e110 -160\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"110 -160\"}' data-mce-style=\"text-align: center;\"\u003e110 -160\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":1950}' data-mce-style=\"text-align: center;\"\u003e1950\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":1630}' data-mce-style=\"text-align: center;\"\u003e1630\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":1650}' data-mce-style=\"text-align: center;\"\u003e1650\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":450}' data-mce-style=\"text-align: center;\"\u003e450\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":24.5}' data-mce-style=\"text-align: center;\"\u003e24.5\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"VFCC450\/2.4\"}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eVFCC450\/2.4\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"110 -160\"}' data-mce-style=\"text-align: center;\"\u003e110 -160\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"110 -160\"}' data-mce-style=\"text-align: center;\"\u003e110 -160\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":2410}' data-mce-style=\"text-align: center;\"\u003e2410\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":2090}' data-mce-style=\"text-align: center;\"\u003e2090\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":2110}' data-mce-style=\"text-align: center;\"\u003e2110\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":450}' data-mce-style=\"text-align: center;\"\u003e450\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":29}' data-mce-style=\"text-align: center;\"\u003e29\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"VFCC450\/3\"}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eVFCC450\/3\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"110 -160\"}' data-mce-style=\"text-align: center;\"\u003e110 -160\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"110 -160\"}' data-mce-style=\"text-align: center;\"\u003e110 -160\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":3025}' data-mce-style=\"text-align: center;\"\u003e3025\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":2705}' data-mce-style=\"text-align: center;\"\u003e2705\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":2725}' data-mce-style=\"text-align: center;\"\u003e2725\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":450}' data-mce-style=\"text-align: center;\"\u003e450\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":34.5}' data-mce-style=\"text-align: center;\"\u003e34.5\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"VFCC450225\/2 (Twinwall)\"}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eVFCC450225\/2 (Twinwall)\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"150−225\"}' data-mce-style=\"text-align: center;\"\u003e150−225\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":150}' data-mce-style=\"text-align: center;\"\u003e150\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":2000}' data-mce-style=\"text-align: center;\"\u003e2000\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":1700}' data-mce-style=\"text-align: center;\"\u003e1700\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":1755}' data-mce-style=\"text-align: center;\"\u003e1755\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":450}' data-mce-style=\"text-align: center;\"\u003e450\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":26}' data-mce-style=\"text-align: center;\"\u003e26\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"VFCC450225\/2.4 (Twinwall)\"}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eVFCC450225\/2.4 (Twinwall)\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"150−225\"}' data-mce-style=\"text-align: center;\"\u003e150−225\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":150}' data-mce-style=\"text-align: center;\"\u003e150\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":2370}' data-mce-style=\"text-align: center;\"\u003e2370\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":2070}' data-mce-style=\"text-align: center;\"\u003e2070\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":1755}' data-mce-style=\"text-align: center;\"\u003e1755\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":450}' data-mce-style=\"text-align: center;\"\u003e450\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":31}' data-mce-style=\"text-align: center;\"\u003e31\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"VFCC450225\/3 (Twinwall)\"}' data-mce-style=\"text-align: center;\"\u003e\u003cstrong\u003eVFCC450225\/3 (Twinwall)\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":2,\"2\":\"150−225\"}' data-mce-style=\"text-align: center;\"\u003e150−225\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":150}' data-mce-style=\"text-align: center;\"\u003e150\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":3000}' data-mce-style=\"text-align: center;\"\u003e3000\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":2700}' data-mce-style=\"text-align: center;\"\u003e2700\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":1755}' data-mce-style=\"text-align: center;\"\u003e1755\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":450}' data-mce-style=\"text-align: center;\"\u003e450\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\" data-sheets-value='{\"1\":3,\"3\":37.5}' data-mce-style=\"text-align: center;\"\u003e37.5\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003cspan style=\"text-decoration: underline;\" data-mce-style=\"text-decoration: underline;\"\u003e\u003cstrong\u003e\u003c\/strong\u003e\u003c\/span\u003e \u003cbr\u003e\u003cspan style=\"text-decoration: underline;\" data-mce-style=\"text-decoration: underline;\"\u003e\u003cstrong\u003eGuidance Documents \u003cbr\u003e\u003c\/strong\u003e\u003c\/span\u003e\n\u003cp\u003eThe FlowBrake mini meets the criteria of the following SuDS design documents\u003c\/p\u003e\n\u003cp\u003eBS 8582 9.6\u003c\/p\u003e\n\u003cp\u003eCIRIA 753 10.2, 20.5  \u003cbr\u003e\u003c\/p\u003e\n\u003cp\u003eThe FlowBrake mini has a minimum opening of 20mm which is considered suitable where upstream blockage prevention is in place.\u003c\/p\u003e\n\u003cp\u003e\u003c!-- split --\u003e DAT file for 20mm inlet: 20mm outlet\u003cbr data-mce-fragment=\"1\"\u003e\u003cbr data-mce-fragment=\"1\"\u003eDAT file for 25mm inlet: 25mm outlet\u003cbr data-mce-fragment=\"1\"\u003e\u003cbr data-mce-fragment=\"1\"\u003eDAT file for 36mm inlet: 36mm outlet\u003cbr\u003e\u003c\/p\u003e\n\u003cp\u003e \u003c\/p\u003e\n\u003cp\u003e\u003ca href=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0829\/4323\/files\/VFCC300_VFCC450_DATA_SHEET.pdf?v=1697456667\"\u003e\u003cstrong\u003eVFCC300\u0026amp;450 Data Sheet\u003c\/strong\u003e\u003c\/a\u003e\u003c\/p\u003e"}
