Vortex flow control shaft VS-Control flex M

£1,099.00
Maximum quantity available reached.

The vortex flow control shaft can regulate flows of up to 65 l/s. The vortex flow control shaft VS-Control External is ideal for retention systems fitted with EcoBloc elements or retention tanks.

  • Continuously variable installation depth of 985 mm – 6500 mm (38.8" – 21' 4")
  • Minimal height offset between the inlet and the outlet (315 mm (12.4") VS-Control External S; 445 mm (17.5") VS-Control External M; 505 mm (19.9") VS-Control External L)
  • Individually adjustable outflow value
  • Support in the planning and dimensioning of our system
  • Housing can be shortened

Versatile use

  • With storage modules, welded into watertight plastic liners
  • With underground tanks
  • With retention tanks provided by the customer

Project-specific design

  • Flexible adaptation to the local site conditions using GRAF shaft components
  • Project specific dimensioning of the replaceable orifice
  • Different shaft sizes for individual requirements

Reliable in operation

  • No wear because there are no moving parts
  • Low-maintenance, because of the self-cleaning-effect through vortex flow
  • Extremely good revision capability
