This below ground rainwater EcoBloc Maxx attenuation crates are an excellent solution for drainage areas for which SUDS are required. Perfect for areas where infiltration is possible due to due good drainage conditions (sand, silt, gravel etc.). If you do not have these conditions please see our attenuations tanks. The EcoBloclight is suitable for pedestrian loading.
This package provides the perfect solution to satisfying planning and building control.
The units are manufactured in the Germany from MDPE. This is a very solid construction dissimilar to other thin walled tanks available.
- EcoBloc light crates
- Ecoblock Light base plates
- Ecoblock Light end plates
- Ecoblock connectors
- Non Woven geotextile NW8 100g/m2
- Full installation instructions
If you require a calculation to confirm the size of your soakaway please confirm the following:
Collection area - m2
Infiltration rate of soil/soil type: -m/hr if the infiltration test has been completed if not soile description sand, silt clay etc.
Loading required - Pedestrian or Vehicle
Features and Beneifts
High storage volume
GRAF infiltration modules have three times the storage volume of a standard gravel infiltration ditch. One module therefore takes the place of around 1300 kg (1,4 tons) of gravel or a 50 m (164') drainage pipe. Since you don‘t have to excavate so much soil and enjoy great value for money compared with a standard gravel infiltration ditch, the GRAF modules save you hard-earned cash!
Service life of over 50 years
A durable product design ensures sustainability. The GRAF EcoBloc system and the Vario 800 flex shaft system is designed for a service life of over 50 years.
Easy to install
The modules are fitted simply, at speed and in various ways. They can be installed without heavy machinery – one EcoBloc Inspect flex module weighs just 8 kg (17.6 lbs), only 7 kg (15.4 lbs) for one EcoBloc light unit.
Up to 97 % reservoir volume
The GRAF EcoBloc light has a gross volume of 225 litres (59.4 US gal.) and a reservoir volume of 219 litres (57.9 US gal.). With a reservoir volume in excess up to 97 %, it is a market-leading product. The EcoBloc variants maxx and Inspect flex still offer a reservoir coefficient of 96 % despite their high load-bearing capacity.
Installation depth of up to 4 metres (13'1.4")
Even under very heavy loads, GRAF EcoBloc light modules can be installed at a depth of up to 4 metres (13'1.4"). This means that up to 9 layers are possible. Please consult GRAF when the installation depth is greater than 4 metres.
- 5 years warranty
Eco-friendly product – green logistics:
To save space during transport, the EcoBloc maxx and EcoBloc light modules are stacked into each other. This minimizes transport costs, storage space in stock and CO2 emissions.
The EcoBloc base plate forms the foundations of each EcoBloc system. Up to 10 EcoBloc modules can be fitted on one base plate.
The side faces are sealed with EcoBloc end plates. The EcoBloc system can be adapted to match individual requirements.
